Pumping Units
FIDMASH Fluid Pump Units serve for paraffin removal, cleanout of frozen pipelines and other technological operations requiring heated fluids.
Optionally each unit can be equipped with air compressor for discharge line blowing out after the fluid operation. Pumping units can be used together with coiled tubing units for sand and paraffin removal, cementing and other repair jobs on all types of wells under pressure.
Н504-20 Fluid Pump Unit
Transport base | truck chassis MAZ 6х6 |
Pump rating | 600 h.p. (440 kWt) |
Max working pressure | 15 000 PSI |
Max flow rate (with 2.75” plungers) | 730 l/min |
Burner heat rate | up to 1,2 MWt |
Displacement tank | 2 х 2000 l |
Air compressor | optional |
H504-10 Fluid Pump Unit
Transport base | truck chassis MZKT 8х8 |
Pump rating | 600 h.p. (440 kWt) |
Max working pressure | 15 000 PSI |
Max flow rate (with 2.75” plungers) | 730 l/min |
Burner heat rate | up to 1,2 MWt |
Displacement tank | 2 х 4000 l |
H1000 Twin Pump Unit
Transport base | truck chassis MZKT 10х10 |
Pump rating | 2 х 600 h.p. (440 kWt) |
Max working pressure | 15 000 PSI |
Max flow rate (with 2.75” plungers) | up to 3000 l/min |
Displacement tank | 2 х 2000 l |
